Local permit context for Abilene
Site plan requirements can change with the project, property, reviewing authority and location. We use the information you provide, your survey or plat when available, and the applicable review context to prepare a clear permit-oriented drawing.
Popular permit projects in Abilene
Choose the closest project type to see the drawing scope we typically prepare for that permit.

Pool Site Plans
Pools, decks, equipment and barrier locations.

Fence Site Plans
Fence runs, gates, easements and property context.

Garage / Shed Plans
Detached garages, workshops, sheds and carports.

Home Addition Plans
Additions, remodels, porches and accessory work.

Commercial Site Plans
Retail, office, warehouse and commercial site scopes.

Deck / Patio Plans
Decks, patios, covers and outdoor structures.
Permit drawing services in Abilene
Need more than a site plan? Use this directory to move from property layout into architectural, structural, MEP or permit-support drawings.
Building drawings
What your Abilene site plan may need to show
The exact checklist depends on the project and reviewing authority. Common items include:
- Property / lot lines and dimensions
- Existing and proposed structures
- Required setbacks and building lines
- Easements and rights-of-way
- Driveways, parking and site access
- Utilities shown when the scope requires them
- Septic or well locations when applicable
- Drainage or floodplain information when applicable
- North arrow, scale and project notes
- Other items requested by the reviewing authority

More project types we support in Abilene
Browse project-specific permit pages for living-space additions, outdoor structures, accessory buildings and commercial improvements.
Site & commercial
Abilene permit and site-plan guidance
Abilene sits in the Big Country west of Fort Worth, with large lots that suit shops, carports and storage buildings. The City’s list of work needing a permit is specific, including fences over 7 feet and decks over 30 inches.
Site Plans TX prepares permit-ready site plans for Abilene properties across Taylor County, drawn from your survey or plat and the scope of your project.
Who reviews permits in Abilene?
Permits are reviewed by City of Abilene Planning & Development Services at 555 Walnut Street. Permits, inspections and contractor credentials are handled through the City’s MyGov portal.
Site development rules are in the Abilene Land Development Code.
What a Abilene site plan needs to show
Requirements vary by project, but Abilene reviewers commonly look for:
- Property lines and dimensions
- Existing and proposed structures
- Setbacks
- Easements and alleys
- Driveways
Local rules that affect Abilene projects
- Carports, fences over 7 feet and storage buildings over 200 square feet or with utilities need permits.
- Front-facing carports may need a special exception.
- Decks with roofs or walking surfaces over 30 inches need permits.
- A permit expires if work has not started within 180 days or stops for more than 180 days.
Projects we draw site plans for in Abilene
In Abilene we most often prepare plans for carports, storage buildings, shops, decks, fences and new homes. Every plan is drawn for the actual lot, with dimensions the reviewer can check quickly.
Before you submit in Abilene
- Check if a carport needs a special exception
- Size storage buildings carefully
- Start within 180 days
- Show alleys and easements
Source: City of Abilene official permit information. Requirements change, so confirm current rules with the City before you submit.



One team for the drawing scope around your site plan
Some permits stop at a site plan. Others expand into architectural, structural, MEP or Texas PE-reviewed work. We can coordinate the next drawing scope when the project requires it.
- Residential and commercial permit plans
- Structural drawings and calculations
- MEP coordination where included in scope
- Texas PE review where required and professionally accepted
How it works
Send the property details
Share the address, project type, survey or plat if available, and any permit comments.
We confirm the drawing scope
We review the information and identify the likely site-plan or permit drawing scope.
Receive the permit drawings
We prepare the agreed drawings and support covered drafting revisions if the reviewer comments.
Abilene site plan FAQs
Do I need a site plan for a permit in Abilene?
Most new buildings, additions and site improvements in Abilene need a drawing that shows where the work sits on the lot. Permits are reviewed by City of Abilene Planning & Development Services at 555 Walnut Street. Smaller projects may only need a marked survey, so confirm the requirement for your specific scope.
Where do I submit permit drawings in Abilene?
Permits, inspections and contractor credentials are handled through the City's MyGov portal.
What should a Abilene site plan show?
Typically property lines and dimensions, existing and proposed structures, setbacks, easements and alleys, plus any items the reviewer asks for on your project.
Can Site Plans TX guarantee approval?
No. The City of Abilene and any other reviewing authority make the final decision. We draw the agreed site plan from your property information and fix covered drafting comments at no charge.
